Workstations optimized for OnShape. Design faster.
Onshape is a computer-aided design (CAD) software system, delivered over the Internet via a Software as a Service (SAAS) model. It makes extensive use of cloud computing, with compute-intensive processing and rendering performed on Internet-based servers, and users are able to interact with the system via a web browser or the iOS and Android apps. Onshape allows teams to collaborate on a single shared design, the same way multiple writers can work together editing a shared document via cloud services. It is primarily focused on mechanical CAD (MCAD) and is used for product and machinery design across many industries, including consumer electronics, mechanical machinery, medical devices, 3D printing, machine parts, and industrial equipment. Onshape upgrades are released directly to the web interface, and the software does not require maintenance work from the user.
The computers listed below are best for Onshape because they all meet or exceed these system requirements…
System Requirements:
Configure | |
Processor | Intel i9 10700F/10900KF or AMD 5900X/5950X |
Mother board | Asus Z490/X570-P |
Cooling | Corsair H80 V2 Liquid |
Memory | 32GB/64GB/128GB 3200MHz DDR4 |
Boot Drive | Samsung 980 PRO Up to 7000MB/s |
Storage Drive | See Options |
Video Card | RTX 3070/3080/3090 |
Video Card | - |
Case | Fractal Design Define C |
Power Supply | EVGA 850W Power Supply |
Wifi / Bluetooth | Available |
Warranty | 1 Year Parts & Labour Included / Upgradable To 3 |
Configure | |
Processor | AMD Ryzen 5 5600X Intel i7 |
Mother board | Asus Prime H410 or B550 |
Cooling | Stock Air Cooling |
Memory | 16GB/32GB 3200MHz |
Boot Drive | 1TB → 2TB NVME SSD |
Storage Drive | Optional |
Video Card | AMD Radeon Pro |
Video Card | - |
Case | In-Win Compact Slim Case |
Power Supply | In-Win 350W (Amazing Supply) |
Wifi / Bluetooth | Available |
Warranty | 1 Year Parts & Labour Included / Upgradable To 3 |
Configure | |
Processor | AMD Ryzen 9 to Threadripper 24C/48T |
Mother board | Asus X570/TRX40-Pro |
Cooling | Corsair H80i Dual Fan |
Memory | 32GB to 64GB |
Boot Drive | Western Digital 1TB Blue NVMe |
Storage Drive | See Options |
Video Card | AMD Radeon Pro |
Video Card | - |
Case | Fractal Designs Define C |
Power Supply | EVGA 850W |
Wifi / Bluetooth | Available |
Warranty | 1 Year Parts & Labour Included / Upgradable To 3 |
